Reciprocating Elevator

Reciprocating elevator is a common material conveying equipment, which lifts the materials on the pallet from low to high through reciprocating motion to realize vertical transportation of materials. It is suitable for industries and scenarios such as manufacturing, warehousing and logistics, food processing, pharmaceutical industry and logistics distribution. It has the advantages of large lifting height, strong adaptability, high efficiency, high space utilization and safety and reliability.

Send Inquiry

Add To Inquiry

Description

Technical Parameters

Reciprocating Elevator

Product Description

Product Features

Large lifting height: Can be customized as needed, and the lifting height can reach tens of meters to meet the needs of different industries and scenarios.
Strong adaptability: The reciprocating hoist can adapt to pallets of different sizes and weights, and is suitable for various types of material transportation.
High work efficiency: Can realize the rapid vertical transportation of materials, improve work efficiency, and reduce manual operation.
High space utilization: Occupies a small area and can realize the storage and dispatch of a large amount of materials in a limited space.
Safe and reliable: Equipped with safety protection devices such as anti-fall devices, limit devices, etc. to ensure safety during the work process.
Simple maintenance: Uses a silent synchronous belt, which is very quiet during operation. In addition, this mechanism is almost maintenance-free, and compared with the chain drive structure, lubrication and tension adjustment are no longer required.

Parameters

Technical Parameters	Unit	Typical range/value
Rated load	kg/m	≤1000
Equipment height	m	≤20(Maximum height that can be docked to meet)
Boost speed	m/min	≤40
Tranfer speed	m/min	5-15
Maximum lifting height	m	37
Minimum docking height	mm	500
Positioning accuracy	m	±2
Proper temperature	℃	-25-+65
Installation form		Fixed
Motor		SEW/NORD
Operating mode		Manual/single machine/connected machine/maintenance

Application Scenarios

Reciprocating elevators are widely used in the automation production industries such as home appliances, food, beverages, tobacco, postal services, chemicals, mechanical electronics, etc. They are suitable for our conventional packaging materials such as cartons, turnover boxes, cartons, crates, pallets, bags, drums, etc.
